分析例

有機溶剤20成分

Conditions

Column:
Porapak™ QS 80/100
Porapak™ P 80/100
Porapak™ T 80/100
Porapak™ N 80/100
Gaskuropack 54 80/100
Analite:
1.   Methanol
2.   Ethanol
3.   Acetonitrile
4.   2-Propanol
5.   Acetone
6.   Propionaldehyde
7.   Acrylonitrile
8.   1-Propanol
9.   Methyl ethyl ketone
10.  Chloroform
11.  Ethyl acetane
12.  Methyl Cellosolve
13.  Trichloroethylene
14.  Benzene
15.  Trichliroethylene
16.  2-Ethyl Cellosolve
17.  N,N-dimethylformamide
18.  Tetrachloroethylene
19.  Isobutyl acetate
20.  Chlorobenzene
Column Size:
SUS 2m × 1/8 O.D.
Carrier Gas:
He 20 mL/min
Injection:
Direct
250℃(Porapak™ QS、P、Gaskuropack 54)
190℃(Porapak™ N、T)
Injection Vol.:
0.2µL
Detection:
FID
250℃(Porapak™ QS、P、Gaskuropack 54)
190℃(Porapak™ N、T)
Sample Size:
Mixed evenly
※PoraPak™ はWaters Corporationの登録商標です。




保持時間比較 175℃ 一定



Porapak™
P
Porapak™
QS
Porapak™
N
Porapak™
T
Gaskuropack 54
1.
Methanol
0.777
1.408
1.985
2.345
1.122
2.
Ethanol
0.958
2.328
3.440
3.869
1.682
3.
Acetonitrile
1.278
2.973
4.823
5.600
2.090
4.
2-Propanol
1.153
3.758
5.573
5.593
2.623
5.
Acetone
1.207
3.585
4.855
4.887
2.517
6.
Propionaldehyde
1.202
3.552
4.397
4.138
2.502
7.
Acrylonitrile
1.450
4.115
6.195
6.475
2.838
8.
1-Propanol
1.455
4.903
7.643
7.792
3.355
9.
Methyl ethyl ketone
1.840
7.488
10.132
9.412
5.117
10.
Chloroform
2.167
8.107
9.550
7.930
5.478
11.
Ethyl acetate
1.850
8.310
10.267
8.737
5.683
12.
Methyl Cellosolve
2.343
9.048
16.338
18.737
6.053
13.
Trichloroethane
2.497
11.878
12.177
8.855
8.032
14.
Benzene
2.882
12.255
12.690
9.815
8.388
15.
Trichloroethylene
3.058
13.357
13.575
10.118
9.060
16.
Ethyl Cellosolve
3.382
17.102
30.640
31.073
11.398
17.
N,N-dimethylformamide
5.562
21.285
42.135
55.678
13.938
18.
Tetrachloroethylene
5.363
28.435
26.115
17.203
19.338
19.
Isobutyl acetate
4.293
32.257
43.243
29.807
21.998
20.
Chlorobenzene
7.697
41.279
47.020
34.800
28.300
※PoraPak™ はWaters Corporationの登録商標です。






保持時間比較 40℃ - 10℃/min - 250℃(*:40℃ -10 ℃/min - 190℃)



Porapak™
P
Porapak™
QS
Porapak™
N*
Porapak™
T*
Gaskuropack 54
1.
Methanol
5.130
8.020
10.995
11.978
6.788
2.
Ethanol
7.535
11.452
13.877
14.313
10.062
3.
Acetonitrile
8.977
12.497
15.092
15.680
11.025
4.
2-Propanol
9.120
13.917
15.924
15.857
12.477
5.
Acetone
9.181
13.593
15.238
15.190
12.188
6.
Propionaldehyde
9.100
13.520
14.816
14.512
12.100
7.
Acrylonitrile
9.950
14.188
14.249
16.347
12.677
8.
1-Propanol
10.308
15.115
17.415
17.402
15.592
9.
Methyl ethyl ketone
11.633
16.885
19.109
18.333
15.378
10.
Chloroform
12.001
17.169
18.677
17.303
15.562
11.
Ethyl acetate
11.835
17.302
19.190
17.873
15.858
12.
Methyl Cellosolve
12.491
17.635
23.112
24.205
16.092
13.
Trichloroethane
12.773
18.698
20.492
17.808
17.443
14.
Benzene
13.272
18.838
20.815
18.505
17.695
15.
Trichloroethylene
13.568
19.168
21.360
18.722
18.182
16.
Ethyl Cellosolve
14.165
19.993
31.658
30.938
19.758
17.
N,N-dimethylformamide
15.888
20.815
38.528
45.267
21.385
18.
Tetrachloroethylene
15.773
21.945
29.222
22.930
24.750
19.
Isobutyl acetate
15.208
21.998
38.500
29.578
26.055
20.
Chlorobenzene
17.150
23.497
41.480
32.522
30.058
※PoraPak™ はWaters Corporationの登録商標です。
